*Pipe is number 19 on diagram* Hi All, Apologies if this seems like a daft question, bikes almost put back together but I can't for the life of me figure out where it's supposed to connect too? Tried watching a few videos that appear to show both cylinder heads connected to a valve then back to airbox? But still quite unsure. Any help would be appreciated. Thanks Dan
It’s an air box vent/drain. It connects to the air box and the lower end with the flat lips vents to air.
Thanks for reply Ricky. Some reason I thought it was connected to this 'fume cannister' as shown at 0.43 onwards?here - not something I have on my bike?
mine had one.. it's a daft idea as it's almost impossible for it not to get cosy with front cylinder exhaust pipe at some point, as no structure in place (or practically possible) to suspend/hold away from same. I repaired mine just for the second one to also get frizzled away.
